About

ABOUT

RIG UP designs and manufactures upper stage equipment, ensuring wide range of high quality products from smallest component to complete lifting solution. It is reached by having workshop, full control of production process and trustful suppliers only from EU. In cooperation with partners the equipment is already used in the projects in UK, HK and EU.

For more info visit our Linkedin account

Upper stage equipment are used for permanent venues: such as theaters, concert halls, museums, schools and clubs. It is used for lifting and lower weighs: lights, decorations and other equipment required for performance.

PRODUCT CERTIFICATION:
EN 17206:2020 Entertainment technology - Machinery for stage and other production areas - Safety requirements and inspections

Machinery directive 2006/42/EC

Winches

PRODUCTS - WINCHES

Electrical winch

RIG150-1/2/3/4

Electrical winch

RIG250-3/4/5/6

Electrical winch

RIG500-3/4/5/6

Electrical winch

RIG1000-3/4/5/6

ELL 1 500N/150kg

Operation lines 1-4

Travel distance up to (m) 9

Lifting speed up to (m/s) 0.2

Wire rope (mm) 4

Motor power (kW) 0.75

Weight up to (kg) 76

Single brake

ELL 2 500N/250kg

Operation lines 3-6

Travel distance up to (m) 12

Lifting speed up to (m/s) 0.2

Wire rope (mm) 6

Motor power (kW) 1.1

Weight up to (kg) 144

Single brake

ELL 5 000N/500kg

Operation lines 3-6

Travel distance up to (m) 12

Lifting speed up to (m/s) 0.2

Wire rope (mm) 6

Motor power (kW) 2.2

Weight up to (kg) 161

Single brake

ELL 10 000N/1000kg

Operation lines 3-6

Travel distance up to (m) 12

Lifting speed up to (m/s) 0.07

Wire rope (mm) 6

Motor power (kW) 1.5

Weight up to (kg) 168

Single brake

Electrical winch

RIGD150-1/2/3/4

Electrical winch

RIGD250-3/4/5/6

Electrical winch

RIGD500-3/4/5/6

Electrical winch

RIGD1000-3/4/5/6

ELL 1 500N/150kg

Operation lines 1-4

Travel distance up to (m) 9

Lifting speed up to (m/s) 0.3

Wire rope (mm) 4

Motor power (kW) 0.75

Weight up to (kg) 76

Double brake

ELL 2 500N/250kg

Operation lines 3-6

Travel distance up to (m) 12

Lifting speed up to (m/s) 0.3

Wire rope (mm) 4

Motor power (kW) 1.1

Weight up to (kg) 148

Double brake

ELL 5 000N/500kg

Operation lines 3-6

Travel distance up to (m) 12

Lifting speed up to (m/s) 0.3

Wire rope (mm) 6

Motor power (kW) 2.2

Weight up to (kg) 165

Double brake

ELL 10 000N/1000kg

Operation lines 3-6

Travel distance up to (m) 12

Lifting speed up to (m/s) 0.07

Wire rope (mm) 6

Motor power (kW) 1.5

Weight up to (kg) 172

Double brake

Manual lifting winch

RIGM150/250-3/4/5/6

Pulley

P125-1/2/3/4/5/6

Pulley

P250-1/2/3/4/5/6

Pulley

P500-1/2/3/4/5/6

ELL 1,5, 2,5kN

Operation lines 3-6

Travel distance up to (m) 12

Lifting speed up to (m/s) -

Wire rope (mm) 6

Motor power (kW) -

Single manual torque brake

ELL 1 250N/ 125kg

Operation lines 1-6

Wire rope (mm) 5-6

ELL 2 500N/ 250kg

Operation lines 1-6

Wire rope (mm) 6

ELL 5 000N/ 500kg

Operation lines 1-6

Wire rope (mm) 6

PB-F

Universal pulley bracket

PB-U-250-200

Universal pulley bracket

PB-U-250-300

Load Pulley

PL150-6-500

Fixing (x4) for the universal pulley bracket to attach the pulley on/below the beam

Universal pulley bracket,

total length 200mm (fixing on ceiling, fixing on/below a beam 40-100mm)

Universal pulley bracket,

total length 300mm (fixing on ceiling, fixing on/below a beam 100-200 mm)

Load cell pulley block (6 ways),

ELL 5000 N,

accuracy 1-1,5%,

4.0 - 20.0 mA

Controls

PRODUCTS - CONTROLS

STANDARD CONTROL:

CS-24VDC (24V)

LOAD CELL PULLEY CONTROL (EN 17206, USE CASE UC1):

CS-PL

CONTROL WITH POSITIONING:

CS-PO

CONTROL WITH FREQUENCY DRIVE:

CS-FD-1.5

• Function: Up, Down, EPO without key;
• Metal enclosure, black;
• Dimensions: 300x200x120;
• Mounted on a winch;
• Schrack Technik and Schneider Electric components used;
• Include: three contactors, circuit breaker, motor
thermal-magnetic circuit breaker.

• Function: Up, Down, EPO;
• Metal enclosure, black;
• Dimensions: 200x400x120;
• Indicators: STATUS, LOAD, OVERLOAD;
• Screw terminals for power connection;
• XLR 4 connector for Load processor;
• Schrack Technik and Schneider Electric components used.

• Human machine interface - Handheld control with a Weintek touch screen;
• Control up to 4 winches (optional 8, 12, 16);
• Save multiple positions in %;
• Integrated GO button to move to set position;
• Speed control 10%, 20%....100%;
• Naming of axis;
• Fault numbering and dating;
• Schrack and Schneider Electric components used.

• Soft start/stop control with frequency drive Invertek ODP-2 (1.5kW)
• Function: Up, Down, EPO; Adjustable speed
• Metal enclosure, black;
• Dimensions: 400x400x210;
• Schrack Technik and Schneider Electric components used.

ON-WALL CONTROL FOR MULTIPLE WINCHES:

CS-MC-6

ADDITIONAL ON-WALL CONTROL: CS-AC (without a key) / CS-ACK (with a key)

WIRED REMOTE CONTROL: CS-RC

WIRELESS REMOTE CONTROL:

CS-WRC

Function: Up, Down, EPO:
- single winch
- multiple units simultaneously;
• Metal enclosure, black;
• Dimensions: 500x500x210;
• Schrack Technik and Schneider Electric components used;
• To use CS-MC-6 standard control or contactor boxes are required for each winch).

• Function: Up, Down, EPO
• Polycarbonate enclosure;
• Dimensions: 180x110x90
• Mounted on a wall;
• Schrack Technik and Schneider Electric components used.

• Function: Up, Down, EPO;
